Resistor: 6 kΩ
Hex 7305: 22.2 mm (7/8‘‘)
Tipo asiento: plano
Rosca: M18x1.5
Longitud de la rosca: 20.6 mm
Diámetro electrodo: 2.4 mm
Galgado: 0.3 mm (0.011‘‘)
Par de apriete (hierro fundido)
Sin lubricante: 50 Nm (37 ft-lb)
Con Lubricante: 33 Nm (24 ft-lb)
Denso: GI3-5
Beru: 18GZ6-77-2 and Z353
Super Green Ignition
Champion: FB77WPCC
Caterpillar: G3500 Series, G3600 Series.
Cummins: QSV 81G, QSV 91G, QSK 19G, QSK 38G, QSK 45G, QSK 50G, QSK 60G.
Guascor: FG180, FG240, FGLD180, FGLD240, FGLD360, FGLD480, FGLD560, SFGLD480.
Perkins: 4000 Series.
Superior: 1706G2, 1712G1, 2400 G series.
Waukesha: AT25GL, AT27GL Series (13/16“Rch Heads),
F11G / GSI, F18G / GL / GLD / GSID, F2895GL (13/16“Rch Heads), F3521GL, F3524GSI,
H24G / GL / GLD,
L36GL / GLD / GSI, L5108GL, L5115GL (13/16“Rch Heads), L5790GL,
L5794GSI / LT, L7042GL (13/16“Rch Heads), L7044G / GL / GSI,
P48GL / GLD, P5115GL,
P9390GL (13/16“Rch Heads)
